IN THE BOX | |
---|---|
Sales Package | Roland Octapad SPD-20PRO Digital Percussion Pad, Owner's Manual, AC Adaptor |
General | |
---|---|
Brand | Roland |
Model | OCTAPAD SPD-20 PRO |
Color | black |
Pads | Built-in Pads: 8 Four external trigger inputs are provided, allowing you to connect Pads. |
Instruments | Instruments: 900 instruments or greater |
Kits | 200 (Preset: 100) |
Kit Chain | 16 chains (16 steps per chain) |
Layer | 2 layers per pad 2 layers x 2(Head/Rim) per external Trigger |
Instrument /Pad Parameters | Volume Curve Coarse Tune Fine Tune Pedal Bend Decay Output Layer EQ Pad comp Pad Mute Group Pad Link |
Kit Effects | Ambience (5 Types) Kit EQ Kit Comp MFX : 3 systems, 38 types |
Display | 16 characters 2 line (backlit LCD) 7 segments, 3 characters (LED) |
Connectors | PHONES Jack: Stereo 1/4-inch phone type OUTPUT(L/MONO, R) Jacks: 1/4-inch phone type MIX IN Jack: Stereo 1/4-inch phone type EXTERNAL TRIGGER INPUT Jack : 1/4-inch TRS phone type x 4 HH CTRL Jack: 1/4-inch phone type FOOT SW Jack: 1/4-inch TRS phone type MIDI (IN, OUT) Connectors USB MEMORY port: USB A type |
Power Supply | AC adaptor (DC 12 V) |
Current Draw | 500 mA |
Dimension | |
---|---|
Dimension | 450(W) x 350 (D) x 72 (H) mm |
Weight | 3.7 kg |
Warranty | |
---|---|
Warranty Type | Official Manufacturer Warranty |
Warranty Period | 2 year |
